OPTICAL
· Light Source: LED 1000W(customized)
· Expected life: 20,000 hours
· Color temperature: 6,000K
· Focus: High-precision glass lenses, electronic linear HD focus
· Zoom: 5° - 55°
· CRI: Ra≥95,R9≥95,R15≥95
FRAMING
· One set of full process framing system, 4 sets of blades fast movement to form geometric graphics; The graphics can be different shapes and different size
GOBO
· Rotating gobo: 1 rotating gobo wheel with 7 optional glass gobo, variable speed shaking and two-way rotating, 16-bit fine tuning
· Static gobo: 1 static gobo wheel with 8 gobos+ white, variable speed shaking and two-way rotating
COLOR
· CMY: CMY linear infinity color mixing, macros
· CTO linear color temperature adjustment(6,000K-2,700K)
· Color wheel: 1wheel with 6 color filters, realize bidirectional rainbow effects, half color and linear adjustment
ELECTRICAL
· Input: AC 100V-240V 50/60Hz
· Power supply unit IP67 plug in/out
· DMX data in/out: IP67 3-pin seetronic XLR
CONTROL/PROGRAMMING
· Control channel: 37/34/53
· Protocol: DMX512, RDM
· Display: LCD
DYNAMIC EFFECTS
· Pan/tilt: 540°/270°, 16-bit control and automatic return correction
· Iris: 5-100% linear adjustment, multi-macro function e仟ects
· Strobe: 1-25Hz,1-25Hz/s fast strobe with pulse/asynchronous/synchronous strobe e仟ect
· Dimmer: 0-100%linearelectronicdimming,threedimming modes built-in,selectableviaconsoleas required
· Prism: 1 4-facet prism+ 1 linear prism
· Frost: 1 independent frost plate
· Animation wheel: 1 bi-directional rotating wheel
PHYSICAL
· Weight: 34kg
· IP rating: IP66
