OPTICAL
• Light Source: 550W
• Expected life: 20,000 hours
• Color temperature: 6500K
• Focus: High-precision glass lenses, electronic linear HD focus
• Zoom angle: 3° - 45°
• CRI: Ra ≥ 70, High CRI, Ra ≥ 90
GOBO
• Rotating gobo: 7 interchangeable gobos, with variable speed oscillation and bidirectional rotation. The rotating gobo features 16-bit precision fine-tuning.
• Static gobo: 6 static gobos + 1 animation gobo, variable speed oscillation and bidirectional rotation
COLOR
• CMY stepless color mixing, with color macro function. CTO linear color temperature adjustment (6500K-3200K)
• Color wheel: 1 wheel with 9 colors, bidirectional rainbow effects, half-tone effects, and linear adjustment.
ELECTRICAL
• Input: AC 100V-240V 50/60Hz
• Signal in/out : IP67 signal socket (input/output)
• Power in/out: IP67 power socket
CONTROL/PROGRAMMING
• Control channel: 24/20/30
• Protocol: DMX512, RDM
• Display: LCD
DYNAMIC EFFECTS
• Pan/tilt: 540°/270°, 16-bit control and automatic return correction
• Aperture: 5-100% linear adjustment, with multiple macro function effects.
• Strobe: 1-25Hz, synchronized and asynchronous, pulse effects
• Dimmer: 0-100% linear electronic dimming, three built-in dimming modes, which can be easily selected via the control panel according to your needs.
• Prism: 4 prisms with bi-directional rotation
• Frost: 1 frost wheel
PHYSICAL
• Weight: 28kg
• IP rating: IP66
