OPTICAL
• Light source: RGB 576 PCS0.5W, Cool White 114PCS5W
• Expected life: 50,000 hours
• Beam angle: 106°
ELECTRICAL
• Input: AC 100V-240V 50/60Hz
• Maximum Power: 1150W
• DMX data in/out: IP65 3-pin XLR
• Power supply unit IP65 plug in/out
CONTROL/PROGRAMMING
• Control channel: 8/14/18/61
• Protocol: DMX512, RDM
• Display: LCD
• 16-bit control: Dimmer
DYNAMIC EFFECTS
• Strobe: 1-30Hz/s fast strobe with pulse/asynchronous/synchronous strobe effect
• Dimmer: 0-100% linear electronic dimming
• Macro Function: RGB light source is divided into 16 zones with built-in effect macro functions. Cool white light source is divided into 16 zones with built-in effect macro functions.
PHYSICAL
• Weight: 12.5kg
• IP rating: IP65
Technical Specification
Photometric Diagram
Gobos & Colours
Exterior Dimensions
Accessories
Downloads
Product Video
GTD-FX1200-MS
