OPTICAL
• Light Source: RGBW 12LEDs 60W，RGB 96LEDs 1.5W，Cool White 96LEDs 1W，Warm White 96LEDs 1W
• Rated Lifetime: 50,000 hours
• Main Beam Zoom: 5°–35°
ELECTRICAL
• Input: AC 100–240V, 50/60Hz
• Max Power: 900W
• DMX Data In/Out: IP65 3-pin XLR input/output
• Power Input: IP65 power input/output
CONTROL/PROGRAMMING
• Control Channels: 19/29/109/118/178/180
• Transmission Protocol: DMX512, RDM
• Display: LCD
DYNAMIC EFFECTS
• Strobe: 1–25Hz high-speed strobe with pulse, synchronous and asynchronous effects
• Dimming: 0–100% electronic linear dimming
• Main Beam Effects: Individually controllable pixels, capable of projecting sharper beams and achieving color chase effects
• Atmosphere Effects: Cool White / Warm White / RGB ambient light divided into 24 individually controllable zones, with built-in effect macros
• Tilt Angle: Y-axis 190°
PHYSICAL
• Weight: 25kg
• IP rating: IP65
Technical Specification
Photometric Diagram
Gobos & Colours
Exterior Dimensions
Accessories
Downloads
Product Video
GTD-FX6012-BW
